MS-700ADU SERIES Addressable manual station
Product Description
Mircom’s MS-700ADU Series provide manual fire reporting. These high quality, die-cast metal Intelligent Fire Alarm Manual Stations are available in either single or dual action configurations with a permanently attached addressable module. The MS-700ADU Series stations are available as single or dual-action devices with key resets and a permanently attached addressable module. The addressable manual station has a pair of rotary decimal switches which allows for two digit address setting. Pulling the handle initiates the operation of the addressable module. All models are available with CAT-30 keys and mount on a standard single gang back box, Mircom model BB-700 interior surface metal back box, or BB-700WP weatherproof back box.
Features
• Single or Dual Action
• Key resettable
• Permanently Attached Intelligent Addressable Module
• High-gloss red enamel finish
• Plastic break rod
• Meets ADA 5 lb. maximum manual-force
• Mounts on standard single gang box, Mircom’s BB-700 surface metal back box or BB-700WP weather proof back box.
Specifications
The manual station shall be Mircom’s MS-700ADU Series. Operating instructions shall be in raised
English lettering and the unit shall be constructed of high quality die-cast metal and finished in red enamel paint to provide quick identification. Pulling the handle shall initiate immediate operation of the intelligent addressable module. All manual fire alarm stations shall be installed as per the specific requirements outlined in the UL codes, as well as all other applicable national or local codes. Final acceptance is subject to the local authority having jurisdiction.
Switch Rating: 1 Amp @ 30 VDC
0.1 Amp @ 125 VAC
Manual Station Dimensions: 4.9” H x 3.5” W x 2.0” D
Color: Red with raised white letters, white Manual bar with raised red letters.
Current Consumption: Standby: 400 uA
Alarm: 5.5 mA
