Fire alarm control panel 8 loop
Product Description
The GST IFP8 is an intelligent fire alarm control panel. Flush- mounted type housing, dual redundant processor technology capable of connecting over 1900 devices, provides the perfect solution for all medium to large systems.
The system is compatible with the complete range of GST Intelligent detectors, sounders, call points, and interfaces, including intrinsically safe and gaseous extinguishing controls. The IFP8 is manufactured and certified to EN54 parts 2 and 4, BS5839 Par 4. And CPD
The GST programming facilities enables advanced and complex cause and effects to be programmed with ease, including phased and cascade evacuation scenarios.
Added commission features such as duplicate address checking, device mismatch, editing device details and programmed through the control panel that has proved to be highly rated by both commissioning and service engineers.
By utilizing the GST protocol the GST -IFP8 can be networked with up to 240 panels, making this the perfect solution for large decentralized systems such as shopping centers, military camps, industrial complexes, holiday villages etc.
• Listed to LPCB
• 8 x Loops (242) capacity (1936) addressable points
• Maximum 10 Loops Standalone
• Modular constructed for future expansion
• 40 x15 lines Colour Graphical LCD Display
• Up to 999 programmable zones and 140 zone indication
• Auto Programming Day and Night Mode
• Enable and Disable function
• PAS and Acknowledge Function
• Dirty Detector Reporting
• Duplicate Address Checking
• Walk Test Function with optional silent mode
• Can edit device detailed and programmed
• Programmable from PC or Panel
• History record-999 fire incident only and 999 event capacity in non-volatile memory Fully simulation of Cause and Effect
• Advanced user friendly programming software including ‘Fuzzy Logic’
• Networked with all GST Intelligent Fire panels up to 64 panels, Optional CAN BUS, Fiber Optic and LAN Network Interface
• RS 485 mimic and repeater output up 64
• RS 232-USB CRT interface, including GST GMC graphic, Epson commercial printer, and BMS
• Built in Fire Alarm, FPE, Fault and Alarm Router output
• 80 column Panel Printer included
• Built in Battery charger
