The I-9102 Optical Smoke Detector is the ideal device for most applications, due to its excellent linear response to a wide variety of different types of smoke patterns. The unit meets the sensitivity requirement of EN 54 part 7, European Standard and is approved by the Loss Prevention Certificate Board (LCPB).
The unit is aesthetically pleasing with a low profile, unobtrusive design that will complement modern building designs. The unit incorporates an intelligent processor that provides Algorithm map, Built-in A/D converter, Drift compensation, Self Diagnosis and History log.
The integral microprocessor analyses the signal according to factors such as signal strength and rate of increase, then confirms these patterns with the pre-programmed fire scenarios and smoke patterns, for a faster and safer response.
Secure and speedy communication through the onboard processor enables the detector to make its own decision, resulting in greater automation. The sensor and the panels utilize ‘fuzzy logic’- providing almost limitless cause and effect scenarios.
Features include Drift compensation to monitor for any long term changes caused by aging, humidity, temperature, dust, etc. The I-9102 is constantly monitoring and self adjusting and is capable of
updating sensitivity baseline for its sensing element. Even when the detector raises a warning advising that it requires cleaning, the sensitivity remains the same as the day it was installed.
Electronic addressing can be done through a Handheld Programming device (P-9910B), available for purchase separately
Features and Benefits
Built in 8 bit microprocessor
Algorithm maps for faster response and false alarm rejection
Secure and speedy communication
Intelligent Linear Drift compensation
Self diagnosis and history log
Sensing chamber for exceptional dust proof ability
Twin LED for 360º vision
Built-in remote indicator output
