Linear beam detector

Product Description

The Fireray5000-EN Linear Smoke Detector covers distances between 8 m and 100 m. A reflective prism allows for the accurate detection of smoke particles within the given distance range. For ranges between 8 m and 50 m, one prism is sufficient. For ranges between 50 m and 100 m, four prisms are required. The additional prisms are included in the FRay5000‑LR‑Kit Long Range Kit. Key application areas are large halls such as historical buildings, churches, museums, shopping centers, factory halls, warehouses, etc. The Fireray5000-EN Linear Smoke Detector is suitable for use in areas where point-type detectors are not effective The Fireray5000-EN Linear Smoke Detector can be upgraded with one additional FRAY5000-HEADEN Detector Heads. The system controller can control up to two detectors. Each head can be programmed separately
